e-STUDIO400AC

Full-colour high performance in A4

Compact, yet feature packed,with the full power of Toshiba's e-BRIDGE Next technology, the e-STUDIO400AC fits seamlessly into modern business environments and can change the way we process documents.
  • Toshiba's A4 colour system delivers outstanding document output at a speed of up to 40 pages per minute.
  • Its large, fully customisable user interface enables you boost efficiency and tailor workflows to fit your needs.
  • Easy integration into the existing e-BRIDGE Next A3 line.
  • Cloud and mobile print support.

For more information please visit our e-BRIDGE Next page.

Specifications: e-STUDIO400AC

GENERAL

Print & Copy Speed:
40 ppm (A4)
Warm-up Time:
~ 18 seconds from low power mode
Paper Size & Weight:
Cassette: A5-A4, 60-256 g/m²
Bypass: A4 - 98 x 148 mm, banner paper (up to 215.5 x 1.321 mm, 90-163 g/m²)
Paper Capacity:
Cassettes: 550 sheets,
Bypass: 1x 100 sheets,
Max. 3,200 sheets
Inner Output Tray:
250-sheet capacity
Automatic Duplex:
A5-A4, 60-256 g/m²
Controller Type:
Toshiba e-BRIDGE Next
Control Panel:
26 cm (10.1") Multi-Touch Colour Panel
Memory:
Toshiba Secure HDD 320 GB**, 4 GB RAM
Interface:
10Base-T/100Base-TX/1000Base-T,
High-Speed USB 2.0, WLAN*, Bluetooth*, Wi-Fi Direct*
Dimensions & Weight:
520 x 540 x 634 mm (W x D x H), ~ 53 kg

PRINT

Resolution:
600 x 600 dpi, 3 bit
1,200 x 1,200 dpi, 1 bit with PostScript driver only
Page Description Languages:
PCL5e, PCL5c, PCL6 (PCL XL), XPS, PDF and PostScript 3 compatible
Supported Systems:
Windows 10/8.1, Windows Server 2019 (64bit)/Server 2016/Server 2012 R2/Server 2012/, Mac OS X 10.7.5-10.15, Linux/Unix, Citrix, Novell SLES, SAP, AS/400
Network Protocols :
TCP/IP (IPv4/IPv6), IPX/SPX, EtherTalk, NetBios over TCP/IP
Colour Modes:
Auto-Colour (ACS), Colour, Twin Colour, Monochrome
Colour Settings:
ICC profile colour management, RGB substitution, Brightness, Saturation, Contrast, Colour Balance
Mobile Printing :
e-BRIDGE Print & Capture, AirPrint, Mopria Print Service, Google Cloud Print
Print Functions:
Universal Printer Driver, Driver Templates, Driver plug-ins*, Print from USB, Hold print, Tandem printing, E-Mail direct printing

SCAN

Resolution:
Maximum 600 x 600 dpi
Scan Speed:
Dual Scan Document Feeder (DSDF):
up to 80 ipm in colour and 116 ipm in monochrome (300 dpi/duplex)
Scan Modes:
Auto-Colour (ACS), Colour, Greyscale, Monochrome
File Formats:
JPEG, Multi/Single Page TIFF/XPS/PDF, Secure PDF, Slim PDF, PDF/A, PDF/A-2, Searchable PDF* (and other formats like DOCX, XLSX)*
Scan Functions:
WS Scan, Scan to USB, Scan to E-Mail, Scan to File (SMB, FTP, FTPS, IPX/SPX, Local), Meta Scan*, OCR Scan*, Scan to Box (e-Filing), WIA, TWAIN

COPY

Resolution:
Scan: 600 x 600 dpi monochrome, 300 x 600 dpi colour
Print: 600 x 600 dpi, 3 bit,
equiv. 2,400 x 600 dpi with smoothing (monochrome only)
First Copy Output Time :
Colour: ~ 6.3 seconds
Monochrome: ~ 5.1 seconds
Zoom:
Platen: 25-400%, DSDF: 25-200%
Copy Modes:
Text, Text/Photo, Photo, Printed Image, Map, Image Smoothing
Colour Modes:
Auto-Colour (ACS), Full Colour, Twin Colour, Mono Colour, Monochrome
Colour Settings:
Hue, Saturation, Colour Balance, RGB adjustment, 5 one-touch modes
Copy Functions:
Electronic Sort, ID Card Copy, Edge Erase, 2-in-1 / 4-in-1 mode

FAX*

Communication:
Super G3, Internet Fax T.37
Transmission Speed:
~ 3 seconds per page
Compression:
JBIG, MMR, MR, MH
Fax Memory:
1 GB Transmission/Reception
Network-Fax:
Driver for Windows 10/8.1 (32/64 bit), Windows Server 2019/Server 2016/Server 2012 R2/Server 2012
Incoming Fax Routing:
To shared folders (SMB, FTP), E-Mail, e-Filing

SYSTEM & SECURITY

Device Management:
TopAccess for remote administration and configuration
System Features:
e-Filing document server for secure storage, Document distribution and Print-on-Demand (1 public box, 200 user boxes), 12,060 one-touch templates for storage of personalised settings or workflows, Scan/Fax Preview, RIP-while-Print, e-BRIDGE Open Platform*, Embedded Web Browser, Job Skip, PCL Barcode printing, e-BRIDGE Plus embedded apps
Accounting & Security:
Role Based Access, LDAP support, 1,000 department & 10,000 user codes, Card Reader*, Private print, Standard data encryption with Toshiba Secure HDD, Data Overwrite Enabler*, IP and MAC address filter, Port filter, Support of SSL and IPsec* protocols, IEEE802.1x support, CC certified (ISO/IEC15408) with HCD-PP v1.0*, Scan to Secure PDF, Pull-printing*
*:
Productivity and paper specifications are related to a paper size of A4 and a paper weight of 80 g/m² if not otherwise mentioned.
**:
1GB = 1 billion bytes; the actual formatted capacity is less. Available capacity will also be less if software applications are pre-installed.

Accessories

Hardware

  • GD-1370EU - Fax Board
  • KK-2560 - Accessible Arm
  • GE-1230 - FIPS HDD (320 GB)
  • GR-1340 - Panel Ten-Key Option
  • GR-1390 - Caster
  • KD-1071 - Large Capacity Feeder
  • GR-1400 - Internal Card Reader Holder
  • MH-4000 - Desk
  • MJ-1047 - Offline Stapler
  • GR-1380 - Spacer
  • MY-1050 - Paper Feed Unit
  • GN-4030 - Wireless LAN/Bluetooth Module
  • GQ-1280N - Harness Kit for Coin Controller

Software

  • e-BRIDGE Job Separator eX - Print multiple sets of your documents each one identified by a separator page
  • e-BRIDGE Plus for USB Storage - e-BRIDGE Plus for USB Storage
  • e-BRIDGE Job Build eX - Combine multiple documents into one and print them on your Toshiba MFP with this printer driver plug-in
  • e-BRIDGE Plus for Zone OCR - e-BRIDGE Plus for Zone OCR
  • e-BRIDGE Job Point eX - A printer driver plug-in allowing you to print your documents on up to 10 Toshiba MFPs simultaneously
  • e-BRIDGE Plus for Microsoft OneDrive - e-BRIDGE Plus for Microsoft OneDrive
  • e-BRIDGE Plus for Dropbox - e-BRIDGE Plus for Dropbox
